1. Importanti Instructions Safety
Please read and follow these instructions carefully for safe assembly and operation of your FLEXISPOT E5W-UK electric standing desk frame. Adhere to all weight restrictions and consider using additional anchors for enhanced stability, especially if the desk is frequently moved or heavily loaded.
- Assicuratevi chì tutti i cumpunenti sianu presenti è intatti prima di u montaggio.
- Ùn supere micca a capacità di carica massima di 125 kg (275 lbs).
- Mantene i zitelli è l'animali domestici luntanu da u scrivania durante l'operazione.
- Avoid placing objects under the desk that could obstruct its movement.
- Scollegate l'energia prima di pulizia o mantenimentu.
- Aduprate solu l'adattatore di alimentazione furnitu.
2. Produttu Finituview
The FLEXISPOT E5W-UK is a robust electric standing desk frame designed for height adjustability and stability. It features a dual-motor lifting system and a memory control panel.
Imagine: Più diview of the FLEXISPOT EC5 height-adjustable desk frame, showcasing its robust and stable design in various color options (black, grey, white).
Funzioni chjave:
- Electric Lifting System: Powerful dual motors with a three-stage linear motion system ensure smooth and rapid height adjustment at 38 mm/second with low noise (under 50 dB).
- Solid and Robust Construction: The heavy-duty coated steel frame provides stability and supports a load capacity of up to 125 kg (275 lbs). Telescopic crossbars extend from 110 cm to 190 cm to accommodate tabletops from 120 cm to 200 cm in width.
- Humanized Lifting Function: Height adjustment range from 62 cm to 125 cm to suit various user heights and office needs.
- Funzione anticollisione: Protects the desk from collisions with obstacles during height adjustment, enhancing safety.
- Assicuranza di qualità: Each Flexispot desk frame undergoes 10,000 fatigue tests, meeting international standards with CE/BIFMA/RoHS certification.
Image: Illustrates the dual motor system, highlighting specifications such as max load capacity (160kg), low energy consumption (<0.5W), speed (35mm/s), and noise level (under 50dB).
Image: Details the stability and durability features, including 3 lifting columns, height adjustment from 62-127cm, 20,000+ fatigue test validation, and removable foot caps for casters.
3. Setup è Assemblea
The FLEXISPOT E5W-UK desk frame requires assembly. All necessary tools are included in the package. Assembly typically takes 20-25 minutes with clear, top-notch instructions.
Passi di Assemblea:
- Disimballate tutti i cumpunenti è verificate cù a lista di e parti in u manuale inclusu.
- Attach the lifting columns to the foot supports.
- Connect the crossbars between the lifting columns.
- Install the control box and motor cables.
- Mount the control panel to the desired location on the desk frame.
- Secure your chosen tabletop to the assembled frame using appropriate screws (tabletop not included).
- Connect the power cable and ensure all connections are secure.
Image: Displays all components of the FLEXISPOT EC5 desk frame laid out for assembly, including legs, crossbars, control box, and tools, indicating an easy assembly process.
Adjusting Frame Width:
The frame's width is adjustable from 110 cm to 190 cm to accommodate various tabletop sizes (120-200 cm width x 60-80 cm depth). Adjust the telescopic crossbars to match your tabletop before securing it.
Image: Diagram illustrating the adjustable frame width from 110-170cm and suitable tabletop dimensions (120-200cm width x 60-80cm depth).
4. Operating Instructions
The FLEXISPOT E5W-UK desk frame is operated via an intuitive control panel with memory presets.
Image: Close-up of the FLEXISPOT EC5 control panel, featuring a digital height display, up/down buttons, and four memory preset buttons (1, 2, 3, 4), along with a memory set button (M).
Funzioni di u pannellu di cuntrollu:
- Buttoni Su/Ghju (▲ / ▼): Press and hold to adjust the desk height manually. Release to stop at the desired height.
- Display Digitale: Mostra l'altezza attuale di u scrivanu in centimetri.
- Preimpostazioni di memoria (1, 2, 3, 4):
- Ajustate u scrivania à l'altezza desiderata.
- Press the "M" button. The display will show "S-".
- Press one of the number buttons (1, 2, 3, or 4) within 3 seconds to save the current height to that preset.
- Per richiamà una altezza salvata, basta à appughjà u buttone numericu currispundente. U scrivania si moverà automaticamente à a pusizione salvata.
- Sistema anticollisione: The desk is equipped with an anti-collision feature. If the desk encounters an obstacle during movement, it will automatically stop and reverse slightly to prevent damage.
5. Mantenimentu
Regular maintenance ensures the longevity and optimal performance of your FLEXISPOT E5W-UK desk frame.
- Pulizia: Asciugate a struttura di u scrivania cù un pannu dolce èamp pannu. Evitate detergenti abrasivi o solventi. Assicuratevi chì l'alimentazione sia scollegata prima di pulisce.
- Gestione di Cable: Periodically check all cables for wear or damage. Ensure they are neatly routed and not pinched.
- Fissaggi: Verificate di tantu in tantu tutte e viti è i bulloni per assicurassi ch'elli sianu ben stretti. Stringhjiteli di novu se necessariu.
- Verificazione di u muvimentu: Operate the desk through its full height range periodically to ensure smooth movement.
6. Risoluzione di prublemi
If you encounter issues with your FLEXISPOT E5W-UK desk frame, refer to the common solutions below.
| Prublemu | Causa Possibile | Soluzione |
|---|---|---|
| U scrivanu ùn si move micca. | Power cable disconnected, control box loose, overload. | Check power connection. Ensure all cables are securely plugged in. Reduce weight on the desk. |
| Uneven movement or strange noises. | Elementi di fissaggio allentati, ostruzioni, distribuzione irregulare di u pesu. | Check and tighten all screws. Remove any obstructions. Redistribute weight evenly on the tabletop. |
| U sistema anticollisione si attiva spessu. | Obstacles under or above the desk, sensitivity setting. | Clear the area around the desk. Consult the full manual for adjusting anti-collision sensitivity if available. |
| I preset di memoria ùn funzionanu micca. | Not saved correctly. | Re-save the memory presets following the operating instructions. |
Sè u prublema persiste dopu avè pruvatu ste suluzioni, cuntattate l'assistenza clienti di FLEXISPOT.
7. Specificazioni
- Numero di mudellu: E5W-UK
- Marca: FLEXISPOT
- Culore: White (Frame 3 Levels - White)
- Materiale: Alloy Steel (Frame), Metal (Raw Material)
- Dimensioni (L x W x H): 45.87 x 110 x 7.87 cm (packaged); Product dimensions: 116.5P x 32l x 20H cm (assembled, without tabletop)
- Pesu: 29.72 kg (imballate)
- Capacità di carica: Finu à 125 kg (275 lbs)
- Gamma di regolazione di l'altezza: 62 cm à 125 cm
- Velocità: 38 mm/second
- Livellu di rumore: Meno di 50 dB
- Frame Width Adjustment: 110 cm à 190 cm
- Suitable Tabletop Dimensions: 120-200 cm (width) x 60-80 cm (depth)
- Assemblea necessaria: Iè
- Funzioni speciali: Sit-stand desk, Height-adjustable desk, Electric standing desk, Anti-collision function, Memory presets.
- Certificazioni: CE/BIFMA/RoHS (as per product features)
Image: Displays certifications for the FLEXISPOT EC5, including an IGR Institute certificate for ergonomic product and a German Health Award for ergonomic brands.
8. Garanzia è Support
FLEXISPOT stands by the quality of its products.
- Garanzia di Frame: 5 anni
- Garanzia di u mutore: 3 anni
- Assistenza tecnica: Assistenza tecnica gratuita per a vita
For warranty claims, technical assistance, or any questions regarding your FLEXISPOT E5W-UK desk frame, please contact FLEXISPOT customer service through their official website or the retailer where the product was purchased. Please have your model number (E5W-UK) and proof of purchase ready when contacting support.
