Introduzione
The GoHawk TJ4-Q is a powerful 1000W 4-channel amplifier system paired with 4-inch full-range waterproof Bluetooth motorcycle stereo speakers. This system is designed to provide high-quality audio for your motorcycle, ATV, UTV, or other powersports vehicles. It features multiple audio input options including Bluetooth 5.0, AUX, USB, SD card, and FM Radio, all controllable via a convenient wired remote. The speakers are built with durable, waterproof materials for outdoor use, ensuring your music accompanies you on every adventure.
Chì ci hè in u Box
Upon opening your GoHawk TJ4-Q package, you will find the following components:
- 1 x Ampunità di lifier
- 4 x Speakers (4-inch full range)
- 1 x Wired Control Unit
- 1 x Cordone d'alimentazione DC
- 4 x Montante Clamps (for 1 to 1.5 inch handlebars)
- 2 x External Antennas (for Bluetooth and FM Radio)
- 1 x Cavu AUX
- Necessary Hardware (screws, fuses)
- 1 x Manuale d'utilizatore
Below is an illustration of all components included in the package:
Figure 1: GoHawk TJ4-Q System Components
For a visual guide on unboxing and reviewing the components, please watch the official video below:
Video 1: GoHawk TJ4-Q Motorcycle ATV Speakers Open Box Video. This video provides an unboxing and review of the GoHawk TJ4-Q amplified stereo speakers, demonstrating the contents of the package and initial setup steps.
Installazione è installazione
Muntà i parlanti
The GoHawk TJ4-Q speakers are designed for easy installation on handlebars ranging from 1 to 1.5 inches in diameter. The included X-Large Mounting Clamps ensure a secure fit. Follow these steps to mount your speakers:
- Attach the larger bracket of the mounting clamp to the speaker, ensuring the loop faces outwards.
- Secure the smaller screws into the four designated slots on the bracket.
- Place the other side of the mounting bracket into position.
- Insert the longer screws through the back, ensuring the screws face outwards, and tighten them to secure the bracket to the speaker.
- Attach the assembled speaker and bracket to your motorcycle's handlebar using the appropriate clamp size. The clamps are 360-degree adjustable for optimal positioning.
Figure 2: Speakers Mounted on Handlebar
Figure 3: Speaker Mounting Mechanism
Istruzzioni di cablaggio
Proper wiring is crucial for the system's performance. Refer to the wiring diagram and instructions below:
- Cunnessione di putenza: Connect the DC power cable to the amplifier's DC 10-16V input. Ensure the red wire connects to the positive (+) terminal of your 12V power source (e.g., motorcycle battery) and the black wire connects to the negative (-) terminal.
- Cunnessione di parlante: Plug each of the four speaker cables into the corresponding RCA (R-SP for Right Speaker, L-SP for Left Speaker) output ports on the amppiù vivu.
- Wired Control Connection: Connect the wired control unit's cable to the 'RE' jack on the amppiù vivu.
- Cunnessione antenna: Attach the two external antennas to the 'BT' (Bluetooth) and 'AT' (FM Radio) ports on the amppiù vivu.
Figura 4: AmpSchema di cablaggio di l'affidatore
Istruzzioni di funziunamentu
The GoHawk TJ4-Q system offers versatile control and audio input options.
Accensione è Selezzione di Modu
- To turn the unit ON or OFF, press and hold the top button on the wired control.
- To cycle through different audio modes (Bluetooth, FM Radio, Auxiliary Input), short press the top button on the wired control. The LCD display on the amplifier will indicate the current mode.
Cunnessione Bluetooth
To connect your smartphone or other Bluetooth device:
- Assicurà u amplifier is powered on and in Bluetooth mode. The Bluetooth indicator on the amplifier's display will flash.
- In u vostru dispositivu, attivate u Bluetooth è cercate i dispositi dispunibili.
- Select "GOHAWK" from the list to pair. A voice prompt will confirm "Bluetooth is connected" once successful.
Wired Control Functions
The wired control provides convenient access to key functions:
- Power ON/OFF: Appughjà è mantene u buttone superiore.
- Cambia di modu: Short press the top button.
- Ajuste di u voluminu: Aduprate i buttoni "+" è "-".
- Track/Station Navigation: Use the 'Previous' and 'Next' buttons.
- Play/Pause: Use the 'Play/Pause' button.
Other Audio Inputs
The system supports various other audio sources:
- Ingressu AUX: Connect your device using the included 3.5mm AUX cable to the AUX port on the amplifier. Switch to Auxiliary Input mode via the wired control.
- Carta USB/SD: Insert a USB drive or SD card containing MP3 files into the respective slots on the amplifier. The system will automatically detect and play the files.
- Radio FM: In FM Radio mode, the system will automatically scan for available stations. Use the track navigation buttons on the wired control to change stations.
Figura 5: Amplifier Front and Rear Panels
Mantenimentu
Proper maintenance will extend the life and performance of your GoHawk TJ4-Q system.
Pulizia
Regularly clean the speakers and amplifier unit. Use a soft, damp cloth to wipe down surfaces. Avoid using harsh chemicals or abrasive cleaners, which can damage the finish or electronic components.
Impermeabilizazione
The speakers are designed with an advanced IP56 waterproof rating, making them suitable for outdoor use and resistant to water splashes. While the speakers are waterproof, the amplifier unit is not. Ensure the amplifier is installed in a location protected from direct water exposure. Always ensure all connections are secure to prevent water ingress.
Figure 6: Speaker Waterproofing
Risoluzione di prublemi
If you encounter issues with your GoHawk TJ4-Q system, refer to the common problems and solutions below:
| Prublemu | Causa Possibile | Soluzione |
|---|---|---|
| Nisun putere | Cunnessione elettrica allentata, fusibile bruciatu, batteria bassatage. | Check all power connections. Replace the fuse if blown (an extra fuse is provided). Ensure your vehicle's battery has sufficient charge (standard 12V). |
| Nisun sonu | Incorrect input mode, loose speaker connections, volume too low, faulty audio source. | Verify the correct input mode is selected. Check all speaker RCA connections. Increase volume. Test with a different audio source. |
| Problemi di accoppiamentu Bluetooth | Device too far, interference, system not in pairing mode. | Ensure your device is within 15 meters (49 ft) of the amplifier. Minimize interference from other electronic devices. Confirm the amplifier is in Bluetooth mode. Try restarting both the amplifier è u vostru dispusitivu. |
| Scarsa ricezione di a radio FM | Weak signal, antenna not properly connected or positioned. | Ensure the FM antenna is securely connected. Try repositioning the antenna for better signal reception. |
For more detailed troubleshooting, please refer to the complete user manual included in your package.
Specificazioni
Key technical specifications for the GoHawk TJ4-Q system:
- Output Wattage: 1000 watts (max)
- Numero di canali: 4
- Oratori: 4" Full Range, Chrome Finished Housing, Waterproof (IP56)
- Amplifier Material: Aluminum (for solid build and better heat dissipation)
- Tipu di muntatura: Handlebar Mount (supports 1 to 1.5" bar size)
- Tecnulugia di cunnessione: Bluetooth 5.0, AUX, USB, SD Card
- Range di Bluetooth: Finu à 15 metri (49 piedi)
- Fonte di energia: Corded Electric (Standard 12V connection)
- Voltage: 16 Volts
- Risposta di Frequency: 4 kHz
- Pesu di l'articulu: 6 liri
- Dimensioni di u pruduttu: Amplifier: 5 x 4 x 4 inches (approximate)
Figura 7: Dimensioni di u produttu
Garanzia è Supportu
GoHawk products typically come with a standard manufacturer's warranty covering defects in materials and workmanship. Please refer to the warranty information provided in your user manual for specific terms and conditions, including warranty period and coverage details.
For further assistance, technical support, or any inquiries regarding your GoHawk TJ4-Q system, please visit GoHawk USA's official website or contact their customer support team. They are available to help with installation questions, troubleshooting, and other product-related concerns.
Ufficiale Websitu: GoldenHawkUSA.com
