Introduzione
Thank you for choosing the Baseus EH10 Adaptive Active Noise Cancelling Headphones. This manual provides essential information for setting up, operating, and maintaining your headphones to ensure optimal performance and longevity. Please read this manual thoroughly before using the product.
Chì ci hè in u Box
The Baseus EH10 package includes the following items:
- Baseus EH10 NC Headphones
- Cavu Dati USB-C
- Manuale d'usu
Image: Contents of the Baseus EH10 headphone box.
Product Overview
Familiarize yourself with the physical components and controls of your Baseus EH10 headphones.
Cumpunenti di l'auriculare
Imagine: Generale view of the Baseus EH10 headphones.
Cuntrolli è Ports
The headphones feature intuitive buttons and ports for easy operation:
- Pulsante di putenza: For turning the headphones on/off, playing/pausing music, and managing calls.
- Pulsanti Volume Up / Down: To adjust audio volume.
- Pulsante ANC: To cycle through Active Noise Cancellation modes.
- Portu USB-C: Per carica l'auriculare.
- Jack audio da 3.5 mm: Per cunnessione audio cablata.
Imagine: Dettagliata view di i cuntrolli di e cuffie.
Istituisci
Power On/Off
- Power On: Press and hold the power button for 2 seconds until the indicator light shows a solid blue light for 1 second.
- Spegnimentu: Press and hold the power button for 4 seconds until the indicator light flashes red once and turns off.
Abbinamentu Bluetooth
To connect your Baseus EH10 headphones to a device:
- Assicuratevi chì l'auriculare sò spenti.
- Press and hold the power button for 4 seconds to enter pairing mode. The indicator light will flash red and blue alternately.
- Nant'à u vostru apparechju (smartphone, tableta, urdinatore), attivate Bluetooth è cercate l'apparechji dispunibili.
- Select "Baseus EH10 NC" from the list of devices to connect.
- Once connected, the indicator light will turn solid blue or off, depending on the model.
Video: Demonstrates generic headphone pairing. Note: This video is a general guide and may not feature the exact Baseus EH10 model.
Auto-Reconnection
After the initial pairing, the headphones will automatically reconnect to the last paired device when powered on again, provided the device's Bluetooth is active and within range.
Switching Devices / Forced Pairing
To disconnect from the current device and enter pairing mode for a new device, press and hold both the Volume "+" and Volume "-" buttons for 5 seconds. The indicator light will flash red and blue three times, indicating the headphones have disconnected and re-entered pairing mode.
Istruzzioni di funziunamentu
Music Control
- Play/Pause: Single-click the Power button.
- Prussima pista: Mantene premutu u buttone Volume Up per 1 seconda.
- Pista Precedente: Press and hold the Volume Down button for 1 second.
- Aument du volume : Single-click the Volume Up button.
- Volume Imbruglia: Single-click the Volume Down button.
Call Control
- Rispondi / Finisce a chjama: Single-click the Power button.
- Reject Call: Press è mantene u buttone Power per 1 seconda.
Modi di Cancellazione Attiva di u Rumore (ANC)
The Baseus EH10 features adaptive ANC technology. Use the dedicated ANC button to switch between modes:
- ANC On: Reduces background noise by up to -45dB.
- Modu di trasparenza: Vi permette di sente ciò chì vi circonda mentre ascoltate l'audio.
- ANC Off: Disattiva a cancellazione di u rumore.
Image: Illustration of the -45dB Adaptive ANC feature.
Assistant vocale
Triple-click the Power button to activate or deactivate your device's voice assistant (e.g., Siri, Google Assistant).
Low-Latency Mode (Gaming/Movie Mode)
Double-click the ANC button to toggle Movie Mode on/off. Double-click the Power button to toggle Game Mode on/off. These modes optimize audio for reduced latency during gaming or video playback.
Video: Demonstrates generic smart button controls for music, calls, and modes. Note: This video is a general guide and may not feature the exact Baseus EH10 model.
Carica
The Baseus EH10 headphones offer extended playtime and fast charging capabilities:
- Durata di a batteria: Up to 80 hours with ANC off, and 55 hours with ANC on.
- Carica rapida: Una carica di 10 minuti furnisce circa 10 ore di riproduzione.
To charge your headphones, connect the provided USB-C cable to the charging port on the headphones and a compatible USB power source.
Image: Baseus EH10 headphones showcasing week-long playtime.
Specificazioni
| Feature | Detail |
|---|---|
| Nome di mudellu | EH10 NC |
| Marca | Baseus |
| Culore | Neru |
| Tecnulugia di cunnessione | Wireless (Bluetooth) |
| Tecnulugia di cumunicazione wireless | Bluetooth |
| Controlu di u rumore | Cancellazione adattativa di rumore |
| Fattore di forma di l'auriculare | Over-Ear |
| Posizionamentu di l'arechja | Over Ear |
| Impedenza | 32 Ohm |
| Metudu di cuntrollu | Pulsante |
| Tempu di carica | 10 minutes (for 10 hours playtime) |
| Usi specifichi per u produttu | Travel, Work, Daily Life |
| Dispositivi compatibles | Phones, Tablets, Desktop Computers, Laptops, Mobile Phones, Smart Speakers |
| Dimensioni di l'articulu | 29 x 22 x 6 cm; 410 grammi |
| Paese d'origine | Cina |
Mantenimentu
To ensure the longevity and optimal performance of your Baseus EH10 headphones, follow these maintenance guidelines:
- Pulizia: Aduprate un pannu dolce è asciuttu per pulisce l'auricolari. Evitate l'usu di prudutti chimichi aggressivi o materiali abrasivi.
- Conservazione: Conservate l'auricolari in un locu frescu è asciuttu, luntanu da a luce diretta di u sole è da temperature estreme.
- Evita l'umidità: Ùn espone micca l'auricolari à l'acqua o à l'umidità eccessiva.
- Maneggiate cù cura: Evitate di fà cascà o di sottumette l'auricolari à impatti forti.
Image: Baseus EH10 headphones designed for cloud-like comfort.
Risoluzione di prublemi
If you encounter any issues with your Baseus EH10 headphones, refer to the following common solutions:
- Nisun putere: Assicuratevi chì l'auricolari sianu cumpletamente cariche.
- Ùn si pò micca accoppià: Make sure the headphones are in pairing mode (indicator light flashing red and blue). Turn off and on your device's Bluetooth. Try clearing previous pairings on your device.
- Nisun sonu: Check the volume levels on both the headphones and your connected device. Ensure the headphones are properly connected via Bluetooth or the 3.5mm audio cable.
- Qualità di sonu scarsa: Ensure there are no obstructions between the headphones and your device. Move closer to your device to avoid interference. Check if the audio source quality is high.
- ANC ùn funziona micca: Ensure the ANC mode is activated.
Reset di fabbrica
If issues persist, you can perform a factory reset:
- Press and hold both the Volume "+" and Volume "-" buttons for 10 seconds.
- The LED indicator will blink 3 times once the reset is complete.
Garanzia è Supportu
For warranty information and customer support, please refer to the warranty card included in your product packaging or visit the official Baseus websitu. Conservate a vostra ricevuta d'acquistu cum'è prova d'acquistu per e richieste di garanzia.
